TCETM

Force transducers for the measurement of static and dynamic loads in COMPRESSION and TENSION Nominal Load from 5 kN to 100 kN Class (ISO 376) 00, 0.5 and 1 Linearity and Hysteresis 0,03% Output: 2mV/V

  • Categories: Force transducers
  • Tags:

Force transducer suitable for the calibration of material testing machines and metrological High mechanical resistance Completely made of stainless steel Completely LASER welded Degree of protection IP67 Long term stability On request ATEX certificate (Zones 1 and 21) GAS and DUST

ACCESSORIES

Calibration Report COMPRESSION Calibration Report TENSION ACCREDIA certificate COMPRESSION ACCREDIA certificate TENSION ACCREDIA certificate BIDIRECTIONAL

Joints to be used for COMPRESSION application Loading head (TIC) Spherical loading head (CTS)

Joints to be used for TENSION application. Knuckle joints (ACCEM)

Aluminum cases for transport

Download

Data sheet TCETM
Data sheet ACCEM
Certificate CE
Certificate ATEX
EAC Certificate
